D.A.S. Audio Action-515A

ACTION-515A is an active system designed to deliver a highly versatile solution, from fixed installations to the popular portable PA application. Its rotatable horn with 90º x 60º dispersion means the enclosure can be used horizontally in a fixed installation, as a stage monitor or even as front fill.As part of our company culture, all our systems are developed under a single philosophy: to deliver the highest possible quality in terms of both materials and overall system design. In the ACTION-500 series we use the same birch plywood as our touring systems for a tight, natural warm sound found nowhere else on the market. The series’ full range of active tops is complete with two balanced XLR inputs for mic and line, an additional 3.5 mm mini jack input, and a powerCON connection.The system has a 15MI4 loudspeaker for a more powerful low-frequency response than other tops in the series and an M-34 compression driver for high frequencies which, together with the 1000 Wpeak Class D amplifier, deliver outstanding performance. The DAScontrol interface uses a high-range 24-bit DSP and rear LCD screen to enable the selection of presets, EQ modes, delay, gain control and signal source mix.

Active biamp systemDual-channel 1000 Wpeak Class D amplifierBirch plywood enclosureDurable ISO-Flex paint to withstand the most demanding environmentsDAScontrol interface for easy setup and adjustmentDSP with presets and LCD screenAmplifier Power : 1000 W Peak Class D, BiamplifiedFrequency Range (-10 dB) : 45 Hz – 20 kHzRated Peak SPL at 1 m : 131 dBDispersion : 90º x 60º (Rotatable)Enclosure Material : Birch PlywoodColor/Finish : Black/ISO-flex paintConnectorsInput : 2 X Female XLRAUX Input : 3.5 mm mini JackLoop Thru : Male XLRAC Input : powerCONAC Requirements : 115 V, 2.2 A, 50 Hz/60 Hz, 230 V, 1.1 A, 50 Hz/60 HzDimensions (H x W x D) : 718 x 444 x 375 mm, 28.3 x 17.5 x 14.8 in

SKU: DAS-ACTION515A

Brand: D.A.S. Audio

Weight: 58.000000
