QSC CP8

Compact Powered LoudspeakersHighperformance, superior quality and lasting reliability. These are the hallmarks of the QSC brand and the reason why millions of professionals the world-over have come to trust QSC to help them confidently deliver superior experiences and memorable performances. The CP Series follows in that same tradition while also offering an ultra-compact form factor and class-leading value.The first thing you will notice about the CP Series is its compact design – every line, angle and curve working harmoniously to present a stylish, yet rugged, appearance. Inside, CP is equipped with a highly-efficient, 1000-watt power amplifier, matching transducers and advanced DSP, delivering performance beyond expectations for a loudspeaker of this size. Because of its compact size, CP is remarkably lightweight, making it easy to load, carry, lift and deploy in a wide range of portable and installed applications. Entertainers of all kinds, as well as educators, institutions and houses of worship will appreciate the ability to mix up to three input sources (mic/line, line and music playback device) at once, making CP a great single-box PA system that sets up in seconds. As part of a larger system, CP can be deployed on a speaker pole, used as a floor monitor or as a musical instrument amplifier. System integrators will especially appreciate CP’s lightweight and compact form factor when attaching it to a wall or truss (via optional yoke mount). And all users will enjoy one-touch DSP control with preset contours for the most common audio applications.

Compact and powerful performance1000 Watt peak power Class-D amplifier moduleEasily selected contours for commonly-used applicationsAdvanced DSP with Intrinsic Correction for superior sound quality and speaker protectionDirectivity Matched Transition (DMT) for consistent frequency response across the entire coverage areaLight weight and highly portableProfessional appearance looks great in any applicationUse for main PA, stage monitor, or instrument amplifier35 mm pole socketOptional yoke, tote, and outdoor cover accessoriesComplete EASE and CAD informationCompact Powered LoudspeakersConfiguration : Two-way active loudspeakerLF Transducer : 8 in (203 mm), coneHF Transducer : 1.4 in (35.6 mm) compression driverFrequency Response (-6 dB) : 56 – 20 kHzFrequency Range (-10 dB) : 53 – 20 kHzNominal Coverage Angle : 90° AxisymetricMaximum Rated SPL1 : 124 dBAmplifier : Class D, Peak : 800 W (LF), 200 W (HF)Controls : Power 2 x Gain Mic Boost Push Switch 6-way Contour Selection SwitchIndicators : Power LED 2 x Input Signal LED, Input B MIC selected LED, Limiter active LEDConnectors: 2 x locking XLR/F ¼” combo (Line Input and Mic/Line input), 1 x 3.5 mm TRS (Stereo Input), 1 x IEC power connectorAC Power Input : Universal power supply 100 – 240 VAC, 50 – 60 HzAC Power Consumption 1/8th Power : 100 VAC, 0.75A / 120VAC, 1.0A / 240VAC 0.31AEnclosure Material : PolypropyleneAttachment Points : M10 threaded insertColor : Black (RAL 9011)Grille : 18 Gauge powered coated steelDimensions (HxWxD) : 16.2 x 10.7 x 10.1 in, 411 x 273 x 256 mmRegulatory: EMC, UL, CBOptional Accessories : CP8 Tote, CP8 Outdoor Cover, CP8 Yoke

SKU: QSC-CP8

Brand: QSC

Weight: 25.500000
